Aluminum PCB & housing, excellent heat dissipation performance.
IP65 & IK08 protection grade with 150lm/W light efficiency.
PC milky cover, soft and uniform lighting.
Breathing valve balances internal and external pressure to ensure longer lamp lifetime.
Linkable use/ Dimmable / Sensor/ Emergency options available.
Inquire Now
The maximum number of quantity for linkable installation:
|
Power
|
Input Voltage
|
Numbers
|
|
40W
|
220-240Vac
|
35
|
|
60W
|
23 | |
|
80W
|
17
|
| Model No. |
T561-40W06
|
T561-60W12
|
T561-80W15
|
|
|---|---|---|---|---|
|
Power
|
20W-40W
|
40W-60W
|
60-80W
|
|
| Product Dimension |
84*70*600MM
|
84*70*1200MM
|
84*70*1500MM
|
|
| Efficiency |
150±10lm/W
|
|||
| Luminous Flux |
3000-6000lm
|
6000-9000lm
|
9000-12000lm
|
|
| CCT |
2700K;4000K;5000K;5700K;6500K
|
|||
| Ingress Protection |
IP65 & IK08
|
|||
| Color Rendering Index | Ra>80 | |||
| Beam Angle |
120°
|
|||
|
Driver Brand
|
PHILIPS/BOKE/CUPOWER
|
|||
| Input Voltage |
AC220-240V
|
|||
| Power Factor | >0.95 | |||
|
Driver Type
|
Constant Current (CC)
|
|||
| Luminaire Net Weight | 1.15KG | 1.92KG | 2.3KG | |
| Packing Information | 6PCS/CTN | 6PCS/CTN | 6PCS/CTN | |
| Export Carton Size | 72*30.5*24CM | 132*30.5*24CM | 162*30.5*24CM | |
| Gross Weight | 7.5KG | 12.5KG | 15.5KG | |
| Material | Housing | Aluminum | ||
| Optics | PC milky cover | |||
| Fixture Color | Silver+White | |||
| Storage temperature range | -40~+80℃ | |||
| Storage humidity range | 5-85% | |||
| Operating temperature range | -25~+50℃ | |||
| Operating humidity range | 5-85% RH | |||
| Life Time | 50,000H | |||
| Warranty | 5 Years | |||
| Dimmable | PWM-dimmable | |||
| Driver | Standard | PHILIPS | ||
| Optional | BOKE/CUPOWER | |||
| Installation | Standard | Ceiling mounted | ||
| Optional | Suspending ropes | |||
| Mounting accessories | Standard | Buckle | ||
| Optional | Suspending ropes/ L-shaped support (for subway) | |||
| Optional accessories | ||||
