Shine a Light in Every Corner!
Shine a Light in Every Corner!
Inquire Now
| Model No. |
HB40-C-200W
|
|
|---|---|---|
| Power Adjustable |
200W-150W-100W
|
|
| Product Dimension |
Φ330x125mm
|
|
| Efficiency（Ra>80） |
150±10lm/W
|
|
| Luminous Flux |
200W（30000±2000lm）-
150W（23250±1500lm）-
100W（16000±1000lm）
|
|
| LED Quantity |
580 pcs SMD 2835
|
|
| Efficiency Plus（Ra>80） | 170±10lm/W | |
| Luminous Flux |
200W（34000±2000lm）-
150w（26250±1500lm）-
100W（18000±1000lm）
|
|
|
LED Quantity
|
580 pcs SMD 2835
|
|
| Efficiency Plus(Ra>70) |
185±10lm/W
|
|
| Luminous Flux |
200W（37000±2000lm）-
150W（28500±1500lm）-
100W（19500±1000lm）
|
|
| LED Quantity |
580 pcs SMD 2835
|
|
|
CCT
|
①3000K+5000K
|
|
| ②3000K+5700K | ||
| ③3000K+6500K | ||
| ④4000K+5000K | ||
| ⑤4000K+5700K | ||
| ⑥4000K+6500K | ||
| Ingress Protection |
IP65/IK08
|
|
| Surge protection |
6KV
|
|
| Color Rendering Index | Ra>70/80 | |
| Beam Angle | 60°、90°、120° | |
| Driver Brand | MOSO/LIFUD/SOSEN | |
| Input Voltage | AC220-240V | |
| Power Factor |
0.95
|
|
| Frequency |
50/60Hz
|
|
|
Driver Type
|
Constant Current
|
|
| Luminaire Net Weight | 2.2Kg | |
| Packing Information | 1PCS/CTN | |
| Export Carton Size | 37*37*17CM | |
| Gross Weight | 2.8Kg | |
| Material | Housing | ADC12 |
| Optics | PC | |
| Finish | Powder Coating | |
| Fixture Color | Black | |
| Mounting Option | Ring mounting/Hook Hanging | |
| Storage temperature range | -30℃ - +70℃ | |
| Storage humidity range | 85% max. | |
| Operating temperature range | -40~+45℃ | |
| Operating humidity range | 85% max. | |
| Life Time | 50000 hours | |
| Warranty | 5 Years | |
| Dimmable | 0-10V | |
| Optional Accessories | Sensor | |
| 0.5 meters safety rope | ||
| Power Selectable | ||
