High Mast Light

1. As high as 130lm/w;

2. IP67 for outdoor;

3. Various beam angle options: 30°, 60° , 60°x90°;

4. 300W, 500W, 1000W;

INQUIRY NOW
Outdoor Lighting-High Mast Light

Inquiry Now

Submit

Product Video

Certificates

American market

  • UL
  • DLC Premium
  • cUL

European market

  • TUV
  • GS
  • CB
  • CE
  • RoHS

Australian market

  •  SAA
  • CTick

Sporting venues, highways, freight yards, ports, commercial parking lots, shopping centers, industrial plants, toll plazas, airports, power plants, parks and sports yards.

Outdoor Lighting-High Mast Light
High Mast Light High Mast Light High Mast Light

Specification

Electrical and Photometric Specification

Model Input Voltage Power (W) Luminous
Efficacy
(lm/W)
Flux (lm) Power Factor Beam Angle LED Brand CCT (K) CRI
FYT-T36B-300W AC100-277V
50~60Hz
300 125±5 37500±1500 0.95 30°, 60°, 60°x90° 112PCS PHILIPS SMD3030 3000 4000
5000 6000
>70
FYT-T36B-500W 500 125±5 62500±2500 112PCS PHILIPS SMD3030
FYT-T36B-1000W 1000 125±5 125000±5000 112PCS PHILIPS SMD3030

Mechanical and Environmental Specification

Model Working Environment Storage Temperature Lumen Maintenance (h) Housing Material Product Size (mm) Packing Size (mm) N.W (kg) G.W (kg)
FYT-T36B-300W -40℃~+50℃
0%~90%RH
-40℃~+85℃ >50000 Aluminum 6063 570*363*372 620*390*240 13.2 16.5
FYT-T36B-500W 840*363*372 890*390*240 18.5 22.3
FYT-T36B-1000W 840*768*522 890*790*240 38.5 43.5
Specification -High Mast Light

Installation

Installation - High Mast Light
